Zusätzliche Informationen
YOM : 04/2016
Carrier Engine:
MTU; Output: 460 KW (625 PS) at 1700 1/min, torque 2900 Nm at 1300 1/min, certification in accordance with EURO MOT 4, TIER 4F
Transmission:
ZF TC-Tronic; Automated gearbox with integrated torque converter and hydraulic retarder, 12 forward speeds and 2 reverse; Selectable longitudinal lock included in transfer case.
Kilometers/Operating hours:
19.500 KM
Operating hours carrier: ca. 200 h Superstructure ca. 2600 h
Axles:
18x8x16; 9 axles; axles 3,4,8,9 driven equipped with selectable transverse lock, axles 1-5 and 7-9 steered, axle 6 liftable.
Tyres:
18 x 385/95R25 (14.00R25)
Superstructure engine:
MTU; Output: 210 KW (285 PS) at 2200 1/min, torque 1150 Nm at 1200 - 1600 1/min, certification according to EURO MOT 4, TIER 4F
Telescopic boom:
15,5m - 60m. Single cylinder telescoping system, automatic telescoping; Attachments for all equipment and extensions; 9 sheaves integrated in boom head for max. capacity of 224,5t.
Additional Equipment
Luffing fly jib: 6,0 m – 96,0 m
Fixed jib: 20,0 m – 50,0 m
Lifting capacity:
700t at 3m Radius
Counterweight:
160t
Hook block:
Hook block with ramshorn hook;
250-9-26D (2800 kg) + 100-3-26-D (1800 kg)
Single hook with vertical swivel; red 15-0V-E (900 kg)Mehr anzeigen
