XCMG QY 50 KA
Preis ohne MwSt.
Drucken
INFO
Produktgruppe
All-Terrain-Krane
Marke / Model
XCMG QY 50 KA
Baujahr
2021
Betriebsstunden
2.000 Std.
Land
China
Allgemeine Bewertung
1
2
3
4
5
Mascus ID
5EFFDCE7
PREISANGABE
Währung auswählen
DETAILS
Lagernummer
1
Letzte Inspektion
2025-07-10
Serien Nr.
1
Anzahl der Vorbesitzer
1
Dienstgewicht
58.000 kg
Max. Traglast
50.000 ton
Amtliches Kennzeichen
1
Max. Hebekapazität am Auslegerende
50.000 ton
Min. Auslegerlänge
14 m
Emissionsklasse
Emissionsklasse 5 / Tier V
Auslegerlänge
16 m
Min. Wippausleger
3 m
Länge Wippspitze
15 m
Länge des Kranauslegers
15 m
Hubhöhe
44 m
Hakenhöhe des Krans - horizontaler Ausleger
15 m
Klapp-/Wippspitze
14 m
Motor Kran (Oberwagen)
Benz
Betriebsstd. Oberwagen
857 Std.
Krantyp
Hydraulikausleger
Originalfarbe
Original
Gegengewicht (kg)
14000
Motor Fahrgestell
Original
Motorhersteller
Original
Transportabmessungen (L x B x H)
12680 x 2500 x 3400 mm
Trägertyp
Räderfahrzeug
Informationen zum Zustand/Garantie
Good Condition
Reifenmarke
米其林
Zustand der Bereifung vorne
98
Zustand der Bereifung hinten
2
Produktionsland
China
Lieferbedingungen
FCA, FOB, CIF, EXW
Zertifikate
EPA, CE
Zusatzgeräte
Fly Jib,Hook,Counter Weight,ETC.
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Zubehör
Unterflaschen
Zusätzliche Informationen
Detailed parameters of XCMG QY50KA truck crane
Dimensional parameters
The overall length of the machine is 13,770mm
Overall width of the machine: 2800mm
Overall height of the machine: 3570mm
Wheelbase: 1470+4105+1350mm
Track: 2304/2304/2075/2075mm
Weight parameter
Total mass in driving condition: 42,000 kg
Axle load: Front axle 16,000 kg/rear axle 26,000 kg
Engine parameters
Engine type: D10.38 A - 40 / SC10E380. 1 q4 / WP10.375 E41
Rated engine power: 276/2200kW, 279/2200kW
Engine rated torque: 1500N·m/ (1100-1600) r/min, 1500N·m/1300r/min, 1480N·m/ (1200-1600) r/min
Driving parameters
Maximum driving speed: 80km/h
Minimum turning diameter: 24 meters
Minimum turning diameter of the boom head: 28.158 meters
Maximum climbing gradient: 40%
Minimum ground clearance: 327mm
Approach Angle: 17°
Departure Angle: 11°
Braking distance: ≤10 meters
Fuel consumption per 100 kilometers: 42 liters
Main performance parameters
Maximum rated total lifting capacity: 50 tons
Minimum rated amplitude: 3m
The maximum lifting moment of the basic boom is 1822kN·m
The turning radius at the tail of the turntable: 3482mm
Outrigger parameters
Longitudinal: 5.91m
Horizontal: 6.9m (4.7m)
Crane boom parameters
Main arm length: 11.3-42.7 meters
Auxiliary arm length: 9.2m or 16m
The maximum lifting height of the basic boom is 11.5 meters
The maximum lifting height of the longest main boom is 42.7 meters
The maximum lifting height of the longest main boom and auxiliary boom is 57.7 meters
Working speed parameter
Lifting speed - Main lifting mechanism: 85m/min when fully loaded, 130m/min when unloaded
Outrigger retraction and release - horizontal (simultaneously) : 20 seconds
