XCMG XCA 200
Preis ohne MwSt.
Drucken
INFO
Produktgruppe
All-Terrain-Krane
Marke / Model
XCMG XCA 200
Baujahr
2021
Betriebsstunden
3.000 Std.
Land
China
Allgemeine Bewertung
1
2
3
4
5
Mascus ID
6CEAC4AF
PREISANGABE
Währung auswählen
DETAILS
Lagernummer
1
Letzte Inspektion
2025-07-10
Serien Nr.
1
Anzahl der Vorbesitzer
1
Dienstgewicht
150.000 kg
Max. Traglast
200.000 ton
Amtliches Kennzeichen
1
Max. Hebekapazität am Auslegerende
200.000 ton
Min. Auslegerlänge
14 m
Emissionsklasse
Emissionsklasse 5 / Tier V
Auslegerlänge
16 m
Min. Wippausleger
3 m
Länge Wippspitze
15 m
Länge des Kranauslegers
15 m
Hubhöhe
84 m
Hakenhöhe des Krans - horizontaler Ausleger
15 m
Klapp-/Wippspitze
14 m
Motor Kran (Oberwagen)
Benz
Betriebsstd. Oberwagen
857 Std.
Krantyp
Hydraulikausleger
Originalfarbe
Original
Gegengewicht (kg)
14000
Motor Fahrgestell
Original
Motorhersteller
Original
Transportabmessungen (L x B x H)
15350 x 3000 x 3950 mm
Trägertyp
Räderfahrzeug
Informationen zum Zustand/Garantie
Good Condition
Reifenmarke
米其林
Zustand der Bereifung vorne
98
Zustand der Bereifung hinten
2
Produktionsland
China
Lieferbedingungen
FCA, FOB, CIF, EXW
Zertifikate
EPA, CE
Zusatzgeräte
Fly Jib,Hook,Counter Weight,ETC.
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Zubehör
Unterflaschen
Zusätzliche Informationen
Basic parameters
The overall length of the machine is 15,350mm
Overall width of the machine: 3000mm
Overall height of the machine: 3950mm
Wheelbase: 2650/1650/2900/1650mm
Wheel base: 2590/2590/2590/2590/2590 mm
Axial load: 11650/11650/11650/10020/10020 kg
Maximum driving speed: ≥80km/h
Minimum stable driving speed: 1-1.5km/h
Minimum turning diameter: ≤18.5m
Minimum ground clearance: 307mm
Approach Angle: 18°
Departure Angle: 14°
Fuel consumption per 100 kilometers: 72 liters
Longitudinal span of outriggers: 9.19m
Maximum rotational speed: ≥1.5r/min
The turning radius at the tail of the turntable (at the counterweight point) : 5100mm
Full extension time of the boom: ≤720 seconds
Engine parameters
Chassis engine model: MC13.54-50/MC13.54-61
The rated power of the chassis engine is 338kW
The rated power of the engine on the vehicle is 221kW
Lifting capacity parameters
Maximum rated total lifting capacity: 200 tons
The maximum lifting moment of the basic boom is 6,657 kN·m
Longest main arm: 90 meters
Fixed auxiliary arm: 18.5m
The maximum length of the main boom and auxiliary boom is 118.5 meters
Job performance parameters
Working range: The maximum working range is 84 meters
Load-bearing extension and retraction: The main arm can extend and retract under load at any point within the working condition range. The comprehensive performance is no less than 40% of the rated load, and the maximum performance is 70% of the rated load. It has a wide construction range and the efficiency is increased by 30% to 50%
Variable support: Supports any combination of outrigger extension lengths, flexible operation, safe and stable
Full-action wireless remote control: Operated by a single person, it can achieve the disassembly and assembly of counterweights, foot pads, and auxiliary arms, reducing operational cost input
Other parameters
Hydraulic system: Utilizing advanced hydraulic technology, the system features high working pressure and large flow rate, ensuring that all movements of the crane are completed smoothly, quickly and accurately.
Electrical system: Equipped with an intelligent electrical control system, it features functions such as fault diagnosis and automatic protection, enhancing the reliability and safety of the crane.
Safety devices: A variety of safety devices are installed, such as overload protection devices, moment limiters, height limiters, amplitude limiters, anti-overturning devices, etc., to ensure the safety of the crane during operation
