Emissionsklasse
Emissionsklasse 3A / Tier III
Transportabmessungen (L x B x H)
5710000 x 1865000 x 2545000 mm
Hochlöffel-/Schaufelstiellänge
750 mm
Motorleistung
35 kW (47,6 PS)
Lieferbedingungen
FCA, CPT, FOB, CFR, CIF, EXW
Zusätzliche Informationen
*Originally imported Kubota engine. The engine conforms to China-III emission regulation and features strong power, low fuel consumption, and prominent performance and the aluminum
paralleling radiator features good heat dissipation performance.
*Originally imported hydraulic system. The four-pump constant power control mode is adopted to realize the perfect matching between hydraulic system and engine, reduce the fuel
consumption, and improve the effciency and the double-pump confluence technology is applied for the boom and arm to realize high motion speeds and stable and effcient operations.
*Electro-mechanically integrated intelligent electronic control system with proprietary intellectual property rights. The multi-functional LCD display can realize the data acquisition and
transmission, orientation, control, protection, and remote frmware upgrade and achieve high intelligent control.
*All-new cab with broader vision feld and more reasonable space layout. The air-cushioned seats and the ergonomic control system realize simpler and more comfortable operations and
minimize the driver’s fatigue.
*High reliability traveling mechanism and working device. The application of strength calculation, fnite element analysis, and new structures and new materials for the structural parts
improves the reliability of the structural parts.
*Convenient repairs and maintenances. The application of full-opening front and rear hoods and side gates and the central lubrication system for slewing system realizes convenient and
effcient maintenances and reduces the maintenance costs.
Engine model: Kubota V2607 (Tier 3)
Rated power: 35 kW/2200 rpm
Operating weight: 5.28 tMehr anzeigen
